TCR-H-SI-2C
CONTACT
DOWNLOAD TCR-H-SI-2C Data Sheet
SAMPLE ORDER
OVERVIEW
| Property | Unit | A-Part | B-Part |
|---|---|---|---|
| Material | Silicone | Hardener | |
| Colour | Light grey | Orange | |
| Density @ 23 °C | g/cm³ | 2,2 | 2,2 |
| Mixing Ratio | Weight or Volume | 1 : 1 | 1 : 1 |
| Hardness (7 days @ ~23 °C and 50% rel. F.) | Shore A | 40 | 40 |
| Viscosity (Brookfield) | Pas | 2 | 1.9 |
| Viscosity (Mixed) (Brookfield) | Pas | 1,95 | 1,95 |
| Tensile Strength (7 days @ ~23 °C and 50% rel. F.) | psi | 0,81 | 0,81 |
| Elongation at Break (7 days @ ~23 °C and 50% rel. F.) | % | 30 | 30 |
| Tear Strength (7 days @ ~23 °C and 50% rel. F.) | kN/m | 4,56 | 4,56 |
| Young Modulus (7 days @ ~23 °C and 50% rel. F.) | psi | 4,98 | 4,98 |
| Coefficient of Thermal Expansion (7 days @ ~23 °C and 50% rel. F.) | |||
| Volumetric | 1 x 10-6 /K | 402 | 402 |
| Linear | 1 x 10-6 /K | 134 | 134 |
| Linear Shrinking (7 days @ ~23 °C and 50% rel. F.) | % | 0.03 | 0.03 |
| Pot Life | min | ca. 50 | ca. 50 |
| Curing Time @ 25 °C / 100 °C | 4 Stunden / 6 Minuten | 4 Stunden / 6 Minuten | |
| Shelf Life (from Date of Manufacturing, unopened @ < 30 °C) | Months | 12 | 12 |
| UL Flammability | UL 94 | V0 (5,6 mm) | V0 (5,6 mm) |
| RoHS Conformity | 2015 / 863 / EU | Yes | Yes |
| Technical | |||
| Thermal Conductivity | W/mK | 1.2 | 1.2 |
| Operating Temperature Range | °C | - 70 bis + 250 | - 70 bis + 250 |
| Dielectric Strength | kV/mm | 14 | 14 |
| Volume Resistivity | Ohm-cm | 1,8 x 1014 | 1,8 x 1014 |
| Dielectric Constant | @ 1 kHz | 4,53 | 4,53 |
