TAT-M-SI
CONTACT DOWNLOAD TAT-M-SI Data Sheet SAMPLE ORDERTAT-M-SI is a thermally conductive electrically insulating silicone PSA transfer tape. Through the thermally conductive adhesive the thermal contact is highly improved even at low pressures. Convex and concave surface structures and stack up tolerances are effectively compensated. Materials with different expansion coefficients can easily be bonded. Thus the total thermal resistance is minimised. The tape works well for realizing an effective and cost efficient thermal coupling in a broad field of applications. Above all it is used in applications having little space only and where the permitted weight is limited. Using screws, springs, clips as mechanic fasteners thus becomes superfluous.
PROPERTIES
- Low thermal resistance
- Thermal conductivity: 1.0 W/mK
- High dielectric strength
- Reliable strong adherence on uneven or hardly machineable surfaces
- Neither mixing of components nor curing processes
- Replacement of fasteners e.g. screws clips, etc.
AVAILABILITY
- Sheet 300 mm x 400 mm
- Roll 300 mm x 50 m
- Both side tacky
- Die cut parts
APPLICATION EXAMPLES
Thermal link of:
- CPUs
- RDRAM memory modules
- Flip Chips, DSPs, BGAs, PPGAs
- MOSFETs to heat sinks
- LED
For use in Power supplies / PCs / Telecom engineering / Automotive applications / LED arrays
OVERVIEW
Property | Unit | TAT-M100-SI | TAT-M200-SI |
---|---|---|---|
Material | Ceramic filled silicone PSA adhesive | Ceramic filled silicone PSA adhesive | |
Colour | White | White | |
Thickness | mm | 0,10±0,01 | 0,20±0,02 |
Peel Off Strength (@ 23 °C) @ Aluminum / @ Glass | N/cm | 6.0 / 7.6 | 6.4 / 7.6 |
Shear Strength (@ 125 °C after 10,000 hrs.) | N/cm² | > 200 | > 200 |
RoHS Conformity | 2015 / 863 / EU | Yes | Yes |
UL Flammability | UL94 | V0 | V0 |
Thermal | |||
Thermal Conductivity | W/mK | 1.0 | 1.0 |
Resistance1 | °C-inch/W | 0.28 | 0.49 |
Electric | |||
Breakdown Voltage2 (@ Initial Thickness, 25 °C) | kV AC | 2.0 | 5.0 |
